PRODUCTS UV LED UV-A 3535
| Category | Part Number | Size(mm) | Peak Wavelength(nm) | Optical Power(mW) | Directivity(degree) | Datasheet |
|---|---|---|---|---|---|---|
| 3535 1in1 G1 (Normal) |
LEUVA33U70RL00 | 3.4x3.4x2.37 | 365 | 1000 | 130˚ |
Download |
| LEUVA33U70TL01 | 3.4x3.4x2.37 | 385 | 1200 | 130˚ |
Download |
|
| LEUVA33U70UL01 | 3.4x3.4x2.37 | 395 | 1200 | 130˚ |
Download |
|
| LEUVA33U70VL01 | 3.4x3.4x2.37 | 405 | 1200 | 130˚ |
Download |
|
| LEUVA33U70WL01 | 3.4x3.4x2.37 | 415 | 1000 | 130˚ |
Download |
|
| 3535 1in1 G1 (Narrow) |
LEUVA35T01RL01 | 3.4x3.4x2.37 | 365 | 960 | 55˚ |
Download |
| LEUVA35T01TL00 | 3.4x3.4x2.37 | 385 | 1150 | 55˚ |
Download |
|
| LEUVA35T01UL00 | 3.4x3.4x2.37 | 395 | 1150 | 55˚ |
Download |
|
| LEUVA35T01VL00 | 3.4x3.4x2.37 | 405 | 1150 | 55˚ |
Download |
|
| LEUVA35T01WL00 | 3.4x3.4x2.37 | 415 | 960 | 55˚ |
Download |
|
| 3535 1in1 H1 1.7W (Normal) |
LEUVA33W70RL00 | 3.4x3.4x2.37 | 365 | 1800 | 130˚ |
Download |
| LEUVA33W70TL00 | 3.4x3.4x2.37 | 385 | 1900 | 130˚ |
Download |
|
| LEUVA33W70UL00 | 3.4x3.4x2.37 | 395 | 1900 | 130˚ |
Download |
|
| LEUVA33W70VL00 | 3.4x3.4x2.37 | 405 | 1900 | 130˚ |
Download |
|
| LEUVA33W70WL00 | 3.4x3.4x2.37 | 415 | 1800 | 130˚ |
Download |
|
| 3535 1in1 H1 1.7W (Narrow) |
LEUVA35W70RL00 | 3.4x3.4x2.37 | 365 | 1720 | 75˚ |
Download |
| LEUVA35W70TL00 | 3.4x3.4x2.37 | 385 | 1820 | 75˚ |
Download |
|
| LEUVA35W70UL00 | 3.4x3.4x2.37 | 395 | 1820 | 75˚ |
Download |
|
| LEUVA35W70VL00 | 3.4x3.4x2.37 | 405 | 1820 | 75˚ |
Download |
|
| LEUVA35W70WL00 | 3.4x3.4x2.37 | 415 | 1720 | 75˚ |
Download |
